TV3500
Stainless steel SS304 point fixing
- Stainless steel SS304
- Works with all glass thicknesses
- SS316 on request for corrosion resistance
- For French balconies, stairs and railings
- Dimensions
- Width 44.5 mm · Top part 15 mm · Base 30 mm
- Strength
- 8.8: up to 2 kN · 10.10: up to 3 kN
- Glass thickness
- 6.6.2 / 6.6.2 · 8.8.2 / 8.8.4 · 10.10.2 / 10.10.4 · 12.12.2 / 12.12.4
- Maximum height
- 8.8: up to 1200 mm · 10.10: up to 1400 mm
Price: on request
or call: +359 877 388 184
Detailed information
Description
TV3500 is our stainless steel (304) point fixing.
TV3500 can be used on French balconies, stairs and glass railings. One of the main advantages of this system is that it works with all glass thicknesses. If you wish, these spacers can be made from stainless steel (316) for excellent corrosion resistance.
Specifications
| Width | 44.5 mm |
|---|---|
| Top part | 15 mm |
| Base | 30 mm |
| Strength 8.8 | up to 2 kN |
| Strength 10.10 | up to 3 kN |
| Glass thickness | 6.6.2 / 6.6.2, 8.8.2 / 8.8.4, 10.10.2 / 10.10.4, 12.12.2 / 12.12.4 |
| Maximum height 8.8 | up to 1200 mm |
| Maximum height 10.10 | up to 1400 mm |
| Material | Stainless steel SS304, SS316 on request |
Components
-
Top part
Top-quality series in aluminium EN AW 6063
-
Spacers
Wedge and plastic insert K6500-16 (16 mm), K6500-12 (12 mm)
-
Plastic parts
Tool for inserting wedges.
-
Threaded pin
Corner element for the TV6500 glass railing
Assembly
-
Drill, clean, apply adhesive and set the chemical anchor.
-
Fit the base and the plastic protector.
-
Place the glass.
-
Secure the top spacers.
-
Finished look.
